QNAP TS-1273U
High-performance quad-core NAS with dual 10GbE SFP+ ports

QNAP TS-1273U

QNAP Products
Small Business (SMB) Storage
QNAP 2U 12-bay NAS/iSCSI IP-SAN, AMD R series 4-core 2.1GHz, 64GB RAM, 10GbE connectivity, Single PSU
AMD RX-421ND 4-core 2.1GHz, 64GB DDR4 RAM (max 64GB), 2 x M.2 2280/2260 SATA 6Gb/s SSD slots, 4 x GbE LAN, 2 x 10GbE SFP+ LAN via a PCIe NIC, 350W PSU
#TS-1273U-64G-US
Our Price: $2,849.00
QNAP 2U 12-bay NAS/iSCSI IP-SAN, AMD R series 4-core 2.1GHz, 16GB RAM, 10GbE connectivity, Single PSU
AMD RX-421ND 4-core 2.1GHz, 16GB DDR4 RAM (max 64GB), 2 x M.2 2280/2260 SATA 6Gb/s SSD slots, 4 x GbE LAN, 2 x 10GbE SFP+ LAN via a PCIe NIC, 350W PSU
#TS-1273U-16G-US
Our Price: $2,449.00
QNAP 2U 12-bay NAS/iSCSI IP-SAN, AMD R series 4-core 2.1GHz, 8GB RAM, 10GbE connectivity, Single PSU
AMD RX-421ND 4-core 2.1GHz, 8GB DDR4 RAM (max 64GB), 2 x M.2 2280/2260 SATA 6Gb/s SSD slots, 4 x GbE LAN, 2 x 10GbE SFP+ LAN via a PCIe NIC, 350W PSU
#TS-1273U-8G-US
Our Price: $2,249.00

Click here to jump to more pricing!

Overview:

Powered by a high-performance AMD R-Series quad-core processor with up to 64GB DDR4 RAM, the TS-1273U features dual 10GbE SFP+ ports and provides two M.2 SATA 6Gb/s SSD slots that allows the greatest flexibility in tiered storage configuration and enables cache acceleration. This powerful hardware can also double the encrypted file transfer performance with AES-NI encryption acceleration. The TS-1273U is designed for small and medium-sized businesses looking for private cloud, cross-platform file sharing and collaboration, efficient backup/restoration, storage for virtualization, and to future-proof their IT infrastructure for 10GbE networks with maximized ROI.

  • NAS and iSCSI-SAN unified storage solution
  • Built-in 10GbE SFP+ ports, highly-efficient storage solution for virtualization and on-the-fly media editing & sharing
  • Supports virtualization, containerized apps, centralized storage, backup, sharing, and disaster recovery
  • Secure access with VPN Server & VPN Client
  • Qfiling enables automatic file organization, Qsirch provides full-text file searching, and QmailAgent simplifies managing multiple email accounts
  • The new QVR Pro allows dedicated storage space for surveillance data in the NAS, and leverages the advantages of storage manageability from QTS
  • Expandable storage capacity by using QNAP expansion enclosures or VJBOD (Virtual JBOD)

Specifications:


Ordering Information TS-1273U-64G TS-1273U-16G TS-1273U-8G
CPU AMD R-Series RX-421ND quad-core 2.1 GHz processor, turbo core up to 3.4 GHz
Hardware Encryption Engine Yes, AES-NI
System Memory 64GB DDR4 (4 x 16GB) 16GB DDR4 (2 x 8GB) 8GB DDR4 (2 x 4GB)
Maximum Memory 64GB (4 x 16GB)
Memory Slot 4 x UDIMM DDR4
(For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.)
Flash Memory 512MB DOM
Drive 12 x 3.5"/2.5" SATA 6Gb/s HDDs/SSDs
M.2 SSD Slot 2 x M.2 2280 SATA 6Gb/s SSDs
10Gigabit LAN Port 2 x 10GbE SFP+ port via a preinstalled PCIe network card
Gigabit LAN Port 4 x Gigabit RJ45 LAN ports
PCIe Slot 1 x PCIe Gen 3 (x4), pre-installed with a dual-port 10GbE SFP+ LAN card
USB Port 2 x USB 3.0 port
4 x USB 2.0 port
LED Indicator Status/Power,LAN,USB, Drive 1 - 12
Button Power/Status, Reset
Maintenance Port 1 x 3.5mm console port
Form Factor 2U Rackmunt
Dimension (H x W X D) 89 x 482 x 534 mm
3.5 x 18.98 x 21.02 inch
Net Weight 10.71 kg (23.62 lbs.) 10.68 kg (23.55 lbs.) 10.68 kg (23.55 lbs.)
Operating temperature & Relative Humidity 0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C
Power Suply 350W, 100-240V AC, 50/60 Hz
Fan 2 x 70mm, 12V DC
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.

* Sound Level Test Environment:
Refer to ISO 7779 ; Maximum HDD loaded ; Bystander Position ; Average data from 1 meter in front of operating NAS. Designs and specifications are subject to change without notice.

Documentation:

Download the QNAP TS-x73U Series Datasheet (PDF).
