QNAP Wireless Wi-Fi 6 Network Card - QXP-W6-AX200
Upgrade your NAS or Windows® PC to 802.11ax high-speed wireless connectivity

All Accessories can be found on their respective product pages or you can purchase them below. Can't find the part you are looking for? Contact us today!

Pricing Notes:

QNAP Wireless Wi-Fi 6 Network Card
QNAP WiFi 6 (Intel AX200) PCIe wireless card w/ antenna & brackets for NAS; Giga-byte GC-WBAX200 QNAP Edition
PCIe supported NAS and Windows 10/Linux PCs.
#QXP-W6-AX200
Our Price: $49.00

The QXP-W6-AX200 is a PCIe Gen 2x1 Wi-Fi 6 wireless adapter with an Intel® Wi-Fi 6 AX200 module that supports the IEEE 802.11ax standard (backwards compatible with 802.11a/b/g/n/ac), MIMO 2Tx2R, MU-MIMO TX/RX and Bluetooth 5.0. The QXP-W6-AX200 can be installed in a QNAP NAS, or Windows®/Linux® PC to provide fast Wi-Fi 6 connection speeds. The QXP-W6-AX200 can also be used with Wi-Fi 6 router to deploy Wi-Fi 6 network environment. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.


Wi-Fi 6

The QXP-W6-AX200 supports Wi-Fi 6 802.11ax, provides up to 2400Mbps connection speeds, and is backwards compatible with 802.11acR2/ abgn.

greater connectivity

The QXP-W6-AX200 supports MU-MIMO 2Tx2R, providing greater connectivity with multiple clients; OFDMA increases network efficiency and decreases packet delay.

dual band 2.4GHz/ 5GHz antennae

The QXP-W6-AX200 has dual band 2.4GHz/ 5GHz antennae, multiple angle tilt, and a magnetic base for the best signal strength direction and location.


BSS coloring

The QXP-W6-AX200 supports BSS coloring that marks shared frequencies with a number for easy differentiation.

Bluetooth® 5.0

Bluetooth® 5.0 provides faster speeds and wider range to easily connect to multiple devices.

Notes: Bluetooth® 5.0 is only available when installed in a Windows® PC and requires an internal USB connection.

signal packed with more data

Wi-Fi 6 uses 1024-QAM to provide a signal packed with more data, and enables 25% faster data rates than 256-QAM.

2.8x Faster Connectivity

The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac).

Notes:

  1. Wi-Fi speed and connection quality may vary based on network traffic, environmental factors, Internet speed, client device performance, and the number of other Wi-Fi and radio signals in the immediate area.


Easy Access with a Wireless NAS

With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.

Notes:

  1. System requirements: 64-bit x86-based NAS (Intel and AMD), or ARM-based NAS, with QTS 4.4.3 (or later) with a PCIe Gen 2x1slot. Check the Compatibility List for a full list of compatible NAS.
  2. Some NAS models must update their BIOS to the following versions. You can download BIOS from the Download Center and learn how to update a BIOS here.
    • TS-251B: Q015AR02
    • TS-653B: QY59AR58
    • TS-251D, TS-253D: Q04WAR08
    • TS-453D, TS-653D: Q04MAR12
    • TS-453DU, TS-453DU-RP, TS-853DU-RP, TS-1253DU-RP: Q05PAR03

Easily Set Up a NAS Wireless Network Connection

After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal.

Notes:

  1. Browser Station requires an x86 NAS with at least 4GB RAM.
  2. If the connected Wi-Fi AP blocks the network segment under NAT, the captive portal may not automatically appear.



Use Network & Virtual Switch Open Network & Virtual Switch: Select the designated SSID and enter the password to connect your NAS to wireless network.
Use Qfinder Pro Open Qfinder Pro: Select the designated SSID and enter the password to connect your NAS to the wireless network.
Use Browser Station to open a captive portal Using Network & Virtual Switch or Qfinder Pro: Select the SSID and open Browser Station to enter a password for the captive portal.


Dual Band Antenna with Better Wi-Fi Signals

The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds.

2.4GHz & 5GHz

Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs.

WI-FI signal transmission

The smart antenna function provides superior WI-FI signal transmission.

angle tilt

The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location.

QXP-W6-AX200

#QXP-W6-AX200

Our Price: $49.00

  • Wi-Fi 6 PCIe card
  • Controller IC: Intel AX200 wireless module
  • PCIe interface: PCIe Gen2 x1
  • Theoretical maximum performance: 2.4Gbps (5GHz)
  • Antenna: 2T x 2R
  • Supported operating systems: QTS 4.4.3 or later; 64-bit Windows 10® PC (download and install driver from Intel website); Linux kernel 5.1 or later (download and install driver from Intel website)
  • Hardware requirement: NAS or PC with a PCIe slot, 64-bit processor and operating system.
  • Package contents: 1 x QXP-W6-AX200 card (GC-WBAX200 QNAP edition, a full-height bracket is pre-installed); 1 x installation guide; 2 x half-height low-profile brackets (a standard bracket and a flat bracket for NAS); Windows 10® driver CD.
  • Operating temperature: 0°C ~ 40°C (32°F ~ 104°F)
  • NAS Software Spec:
    • Supports QTS 4.4.3 or later
    • Security Protocol: No Auth / WEP / WPA-Personal / WPA2-Personal
    • Supports the Captive Portal authentication method: Access WiFi via the configuration by Qfinder utility / Browser Station.

* Brand and product names mentioned are trademarks of their respective companies.
